Yucera Dental cadcam system 5axis wet milling machine for glass ceramic block for veneer crown
Advantages
1.-Suitable foo glass ceramics/lithium disilicate, high
toughness porcelain, amber porcelain, resin material,
arbor type zirconia, prefabricated abutment (optional);
2.-Horizontal processing-speed can be increased by nearly
20%;
3.-Simple maintenance- When the all-in-one machine fails,
the after-sales maintenance is more complicated. The
seperated equipment only needs to replace the processing
system to complete the update and maintenance;
4. -Tool detection sensor with 2um
5. -24hours on-line technical support
Machinable Materials:
Dongci glass ceramics, Yiwojia blue/white porcelain,
domestic glass ceramics, vita glass ceramics, vita amber
porcelain, celtra zirconium, lava excellent tough porcelain,
vita elastic porcelain, Dongci zirconia, PMMA polymer resin
and other shaft handles class material.
| Detailed specification of 5 axis dental milling machine: | |
| Axis | 5 Axis |
| Cut Method | wet milling |
| Milling Materials | emax lithium disilicate |
| Size of milling materials | I12;C14;B40 |
| Range of rotation & tling rotation | x/y/z: 105 / 135/ 90 A:360° B:±20° |
| Speed of Principal axis | 0-60000rpm / 500w |
| Driver | Full rotation servo motor drive |
| cutters | 3 tools; |
| size of dental 5aixs milling machine | cutting machine:55KG cnc control:20KG |
| G.W: of dental 5aixs milling machine | CNC machine:95kg; Host milling machine:20kg |
| Compressed Air: | 4.5-7.5bar; |
| Min Capacity-: | 3000L/min |
| Power requirement : | 800W;220-230v AC,56/60 hz |
Packaging Details
1.Outer packaging: standard seaborne export plywood box. 2. Inner packaging: waterproof stretch film and plastic film.
To better ensure the safety of the machine , professional, environmentally friendly, convenient and efficient packaging services will be provided.
